power consumption meter network optical power meter

    Buy cheap power consumption meter network optical power meter from wholesalers

    Buy cheap power consumption meter network optical power meter from wholesalers
    • Buy cheap power consumption meter network optical power meter from wholesalers

    power consumption meter network optical power meter

    Ask Lasest Price
    Brand Name : huayu
    Certification : ISO9001
    Model Number : hy-62
    Price : $60.00/pc
    Delivery Time : 7 days after payment
    Payment Terms : Paypal / Western Union / TT
    Supply Ability : 1000pcs/month
    • Product Details
    • Company Profile

    power consumption meter network optical power meter

    hy-62 fiber optical light source power meter fiber optic equipment China supplier


    850/1300/1310/1490/1550/1625nm

    2.5mm universal and FC, SC, ST;

    Energy save mode;

    Built in VFL (optional);

    Reference value storage;

    Full energy can support above 100 hours;


    Main Characteristic

    Accuracy *

    ± 0.2dB

    Calibrated Wavelengths

    850nm / 1300nm / 1310nm / 1490nm / 1550nm / 1625nm

    Resolution

    0.01dB

    OPM Connector

    2.5mm UPP and FC interchangeable (SC, ST optional)

    VFL Connector

    2.5mm UPP

    Reference Value storage

    Yes

    Auto Power Off

    No operation in 10 minutes (can be canceled), Low battery energy

    Battery Charge

    Yes

    Battery Life

    Above 100 hours (1800mAH battery)

    Temperature

    Storage: -20 -- +60 ℃, < 90%RH Operating: -10 -- +50 ℃, < 90%RH

    Power Supply

    AA * 2 batteries or AC/DC power supply adapter

    Size / Weight

    160mm * 75mm * 32mm / About 180g


    Accessories

    Standard

    Carrying bag

    1

    User’s manual

    1

    Calibration certification

    1

    Optional

    SC interchangeable connector

    1

    ST interchangeable connector

    1

    AC/DC adapter

    1



    Contact us:
    Sales:Cathy Deng
    Skype:cathy02024
    Mobile:+86-13598845323
    Tel:+86-371-65695888
    Fax:+86-371-65720023

    Warm Notice to Users :

    Please fax the “after service form”to our service department within 7 days after buying the products, so that we can verify your product.We will provide you the perfect after -sales service when receiving the form.The following situations are not within the scope of warranty service :

    1. due to personal or non- maintenance units of the company agent disassemble , repair or damage caused by the failure ;

    2. due to force majeure and human factors led to the failure or damage ;

    3. the use of an external power supply voltage is not normal due to malfunction or damage ;

    4. Consumable parts ( eg : Electrical welding electrode rod, cutter blades , OTDR optical connectors and adapters and a variety of battery )
